PowerShareX PSX1204D

Name: PowerShareX PSX1204D adaptable power amplifier
Brand: Bose Professional

PowerShareX PSX1204D adaptable power amplifier

Многоканальный усилитель с DSP для профессиональной аудиосистемы.

Обсудить проект

Особенности

Входные каналы: 4 balanced, line
Разъёмы: (1) 6-pin Euroblock
Input Impedance: 20 kΩ
Maximum Input Level: 20 dBu

Характеристики

Характеристики производителя
Channel Separation (Crosstalk)	-70 dB typical at 1 kHz
Gain, Low-Impedance	26 dB, 29 dB, 32 dB, 35 dB, selectable
Maximum Peak Power, Symmetrical	800 W at 2 Ω / 600 W at 4 Ω, 8 Ω, 70V, 100V
Maximum Peak Power, Asymmetrical	2200 W at 2 Ω, 4 Ω, 8 Ω, 70V, 100V
Rated Power, Asymmetrical	1100 W at 2 Ω / 1100 W at 4 Ω in 70V mode / 1100 W at 8 Ω in 100V mode / 1100 W at 70V, 100V
Frequency Response	20 Hz – 20 kHz (±1.0 dB), 1 W at 8 Ω
Number of Channels	4
Power Class	Class D
Rated Power, Symmetrical	400 W per channel at 2 Ω / 300 W per channel at 4 Ω, 8 Ω, 70V, 100V
THD+N	< 0.1% (< 0.05% typical, from 0.1 W to half-power)
Входные каналы	4 balanced, line
Разъёмы	(1) 6-pin Euroblock
Input Impedance	20 kΩ
Maximum Input Level	20 dBu
Sensitivity	2.48 Vrms at 26 dB gain, 1.76 Vrms at 29 dB gain, 1.24 Vrms at 32 dB gain, 0.88 Vrms at 35 dB gain
Каналы	4 Dante in
Разъёмы (2)	(1) RJ-45 Dante in
Каналы (2)	4
Разъёмы (3)	(1) 8-pin Euroblock, 7.62 mm
Safety	EN 54-16 certified, voice alarm control and indicating equipment
Current Draw, Idle	0.45 A at 115 VAC, 60 Hz / 0.25 A at 230 VAC, 50 Hz
Mains Connector	IEC C20 inlet
Напряжение питания	100–240 VAC (±10%), 50/60 Hz
Protections	High temperature, DC, output short circuit, high frequency, excessively low/high AC mains voltage, inrush current, clip, peak, long-term/RMS
Потребление мощности	31.1 W idle, 251 W maximum at 1/8 power at 4 Ω
Software Applications	ControlSpace Designer 5.12 or later (Windows)
Computer Interface Connection	RJ-45 (Ethernet)
Notification Outputs	(1) 12-pin Euroblock (3 pins per channel), general purpose
Controls, Front Panel	(1) power button, (1) soft reset button, (1) hard reset button, (1) check button, (4) channel attenuation controls
Controls, Rear Panel	16 output DIP switches (4 per channel), 8 system configuration DIP switches
LED Status Indicators	(21) channel meter LEDs, (7) system status LEDs, (2) power status LEDs
Crossover Types	Butterworth, Bessel, or Linkwitz-Riley, up to 48 dB/octave
Audio Latency	2.5 ms, fixed-latency architecture
Processing Functions	Input EQ, array EQ, loudspeaker EQ, peak voltage limiter, RMS voltage limiter, delay, band-pass, matrix mixer
Цвета	Black
Suspension/Mounting	Rack-mounting
Размеры (В × Ш × Г)	19.0 in × 1.8 in × 14.1 in (483 mm × 45 mm × 358 mm)
Масса нетто	15.4 lb (7.0 kg)
Масса при транспортировке	22.8 lb (10.3 kg)
