Veritas 2160BH

Name: Veritas 2160BH
Brand: Bose Professional

Микшер-усилитель для профессиональной аудиосистемы.

Обсудить проект

Особенности

Входные каналы: (2) balanced line, (2) unbalanced line, (1) balanced mic/line
Разъёмы: (2) RCA stereo pairs, (2) 5-pin Euroblock, (1) 4-pin Euroblock
Input Impedance: 20 kΩ (line), 2 kΩ (page)
Input Range: -8 dBu to +22 dBu (line), -58 dBu to +12 dBu (page)

Характеристики

Характеристики производителя
Channel Separation (Crosstalk)	≤ -58 dBu below rated power, 1 kHz
Dynamic Range	88 dB
Frequency Response	20 Hz – 20 kHz (+0/-3 dB) at 1 W, 1 kHz reference
Rated Power, Symmetrical	2 x 160 W at 70/100V
THD+N	≤ 0.5% at rated power
Adjustment Range	0 dB to -30 dB (line), 0 dB to +50 dB (page)
Входные каналы	(2) balanced line, (2) unbalanced line, (1) balanced mic/line
Разъёмы	(2) RCA stereo pairs, (2) 5-pin Euroblock, (1) 4-pin Euroblock
Input Impedance	20 kΩ (line), 2 kΩ (page)
Input Range	-8 dBu to +22 dBu (line), -58 dBu to +12 dBu (page)
Maximum Input Level	22 dBu (line), 12 dBu (page)
Nominal Input Level	4 dBu (line), -38 dBu (page)
Sensitivity	-8 dBu (line), -58 dBV (page)
Каналы	(2) loudspeaker, (1) unbalanced line
Разъёмы (2)	(2) 2-pin inverted Euroblock, (1) RCA stereo pair
Nominal Output Level	2 × 160 W at 70V/100V (loudspeaker), 2 dBu (auxiliary)
Mains Connector	IEC C14 inlet
Напряжение питания	100–240 VAC (±10%), 50/60 Hz
Protections	High temperature, output short circuit, excessively low/high AC line voltage
Потребление мощности	13.6 W standby, 500 W maximum
Controls, Front Panel	Power on/off switch, input select switch (A/Bluetooth/B), rotary encoder
Controls, Rear Panel	Amplifier mode DIP switches, input gain knobs (A, B, page), page threshold knob, mute connector, ControlCenter ports
Audio Latency	10.4 ms (any input to speaker output or aux output)
Processing Functions	Loudspeaker EQ, Opti-Voice paging, Dynamic EQ
Размеры (В × Ш × Г)	44 mm × 483 mm × 324 mm (1.7 in × 19.0 in × 12.8 in)
Масса нетто	4.4 kg (9.7 lb)
Масса при транспортировке	5.8 kg (12.8 lb)
